Core Shifter w/ chrome stick for Toyota Tacoma : 2005-2015 I4 2wd (R155)
*** FILE PHOTO - NOT AS PICTURED! Similar to what is shown but baseplate is larger and has a 6-bolt pattern. Fits the applications described. ***
Short throw shifter kit for OE replacement on 5 speed manual trans in:
- 2005-2015 Toyota Tacoma - 2.7L I4, 2wd only
ONLY FITS R155 manual trans specific to these 4 cyl 2wd trucks
- Does NOT FIT 4x4 (different base), V6, other model years, or any other model
- 15.5" tall from base flange to top of knob; 23% throw reduction
- IF YOU HAVE A 2"+ BODY LIFT (frame spacers) - upgrade to taller stick #0090
- Lower bushing cup not included; reuse existing or buy separately
Kit includes PLAIN chrome stick #4106, classic knob, base assembly, mounting hardware, and installation instructions. The base is built by Core Shifters using proven components inside a custom housing:
- High-strength billet steel gear selector stub
- Hardened steel cross-pin & stainless steel fulcrum pivot ring
- Self-centering cross-gate bias springs with heat treated spring seats
- Glass-reinforced polyamide fulcrum socket with steel wear clips
- Rubber oil control seal with steel retaining ring
- Extruded aluminum housing with Spirolox steel support ring
- Laser-cut steel lid & baseplate
